Key Features
-
Integrated, High-Performance Design
Powered by an octa-core 64-bit processor with 8GB memory, this device integrates video acquisition, encoding/decoding, live streaming, director station, image splicing, and local audio echo in one secure, easy-to-maintain platform. -
Massive Storage & Loop Recording
Built-in 2TB storage supports up to 2,000 hours of content with automatic overwrite and loop recording for uninterrupted long-term use. -
Multi-Channel UHD Video I/O
-
Inputs: 6× HDMI (4K capture), 1× Type-C (1080p capture)
-
Outputs: 4× HDMI (2× 4K + 2× custom channel outputs)
-
Audio: 3.5mm and Phoenix terminal I/O with independent mixing and volume control per channel.
-
-
Advanced Control & Connectivity
Includes RS-232, RS-485, Gigabit Ethernet, fibre network port, USB ports, and I/O triggers for complete integration with external control systems and peripherals. -
Professional-Grade Recording & Streaming
Records up to 9 simultaneous video streams in MP4, AVI, MOV, FLV, TS, or MKV formats. Supports scheduled recording, one-click file copying, and real-time file upload to FTP servers or cloud platforms. -
Built-In Director & Scene Control
7-inch touch panel and web-based interface allow preview, multi-screen layout control, switching effects (12 transitions), subtitle overlays, watermark/logo insertion, and scene recall. -
Interactive Teaching & Multi-Room Collaboration
Supports multi-host interaction (up to 4 units) and MCU integration for up to 50 units. Includes dual-screen display, discussion/mute modes, address book, classroom convening, and remote screen layout control. -
AI-Powered Tracking
Intelligent teacher/student tracking with adjustable frame size, height adaptation, shielding zones, and auto-lock release. Ensures smooth, centred tracking with panoramic switching for multiple participants. -
Flexible Streaming & Live Management
-
Stream to 200 users simultaneously on LAN or push to third-party platforms via RTMP (up to 3 streams).
-
Schedule start/end times and expand audience reach effortlessly.
-
-
Security & User Management
Supports encrypted recording with dual encryption modes, group-based user access control, and password/U-shield authentication for playback.
Software Features
-
Web-Based Management (B/S Architecture): Online directing, signal and group management, file preview/playback, scheduled recording, and system configuration.
-
Customizable Output: Resolution, frame rate (15/20/25/30/60 fps), bit rate (256Kbps–20Mbps), and aspect ratio (16:9, 9:16, 32:9) settings.
-
Audio Processing: Supports AAC, PCM, G.711, ADPCM formats with audio mixing control and volume adjustments per input.
-
Playback Control: Local or network playback with variable speeds (0.5× to 3×) and popular/latest video modules.
-
Firmware Upgrade: One-click system upgrades for function expansion and feature enhancements.
Ideal Applications
-
Hybrid Classrooms & Lecture Capture – Intelligent teacher tracking, multi-camera recording, and live student participation.
-
Corporate Training & Webinars – Professional live streaming with scene branding, subtitles, and multi-source mixing.
-
Conference & Event Recording – Multi-angle UHD capture, live switching, and secure archiving.
-
Command & Control Centres – Multi-stream decoding and real-time content distribution with redundant storage.
